Name: SL - F34 Textile Anti - Hook Tester Nail Hammer Hook Performance Tester
Brand: SKYLINE INSTRUMENTS CO.,LTD
SKU: SL-F34
Price: 4,500.00 USD
Availability: InStock

Home Products Textile Testing Equipment

SL - F34 Textile Anti - Hook Tester Nail Hammer Hook Performance Tester

Product Details:

Place of Origin:	CHINA
Brand Name:	SKYLINE
Certification:	CE
Model Number:	SL-F34

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Packaging Details:	plywood case
Delivery Time:	10-15 days
Payment Terms:	MoneyGram, Western Union, T/T, D/P
Supply Ability:	1 unit/ week

Contact Now

Detailed Product Description

SKYLINE:	Nail Hammer Hook Performance Tester	Number Of Stations:	4 Stations
Rotating Speed:	60±2r/min	Counting Range:	0~99999
Felt Thickness:	3 ~ 3.2mm; Width 165mm	Power:	AC220V, 50Hz, 200W
Highlight:	textile lab equipment , textile testing instruments

SL-F34 Nail Hammer Hook Performance Tester

Use
It is used for the anti-hook performance test of knitted fabrics and other easy-to-hook fabrics.

Standards compliant
GB11047, ASTM D3939.

Technical Parameters

Number of stations	4 stations
Rotating speed	60±2r/min
Counting range	0~99999
The diameter of the drum	Φ82mm; width 210mm
The quality of the hammer	160 ± 10g
The number of nails implanted	11
Needle nail exposed length	10mm; tip radius R0.13mm
Felt thickness	3 ~ 3.2mm; width 165mm
The working width of the guide rod	125mm
Distance between nail hammer and guide rod	45mm
Power	AC220V, 50Hz, 200W
The external dimensions	630 × 450 × 650 mm
Weight	60kg
