Name: Crockmeter Electronic to Determine Colour Fastness of Textiles to Dry or Wet Rubbing
Brand: SKYLINE
SKU: SL-F36
Rating: 4.8 (166 reviews)

Home Products Textile Testing Equipment

Crockmeter Electronic to Determine Colour Fastness of Textiles to Dry or Wet Rubbing

Product Details:

Place of Origin:	CHINA
Brand Name:	SKYLINE
Certification:	CE
Model Number:	SL-F36

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	Textile Testing Equipment
Packaging Details:	plywood case
Delivery Time:	5 work days after order confirmation
Payment Terms:	MoneyGram, Western Union, T/T, D/P
Supply Ability:	15 unit/ week

Contact Now

Detailed Product Description

SKYLINE:	Crockmeter Electronic	Rubbing Head:	Dia.16mm
Vertical Pressure:	9N+/-10%	Rubbing Stroke:	104±3mm
Rubbing Speed:	Adjustable	Counter:	LCD, 1-999,999times, Automatically Stops
Highlight:	textile lab equipment , textile testing instruments

Crockmeter Electronic

Crockmeter Maual.pdf

Product Information
Electronic Crockmeter, to determine the colour fastness of textiles to dry or wet rubbing. A pinned acrylic sample holder ensures rapid sample mounting and repeatability of results.this crockmeter Fitted with a pre-determined electronic counter for strokes up to 999,999 times

Specification

Rubbing head	Dia.16mm
Vertical pressure	9N+/-10%
Rubbing stroke	100mm
Rubbing speed	adjustable
Counter	LCD, 1-999,999times, automatically stops

Original Accessories

AATCC rubbing clothing	10 pcs
Sand paper	2 (pcs)
Rings	2 (Pcs)
Dimension	950×340×390mm(L×W×H)
Power	1HP, AC220V, 50HZ, 60W
Weight	22KG

Testing Standards
GB/T3920-2008,GB/T420,GB/T5712

Crockmeter Maual.pdf

What is Crockmeter test?

The Crockmeter provides a quick and accurate method to determine the amount of color transferred from textile materials (such as fabric, carpeting, yarn and leather) to other surfaces by rubbing. The Crockmeter has also been employed to perform rub abrasion, scuff and / or mar tests on flat specimens.
