ISO7211.2 Textile Testing Equipment , SL - F20 0~50mm Fabric Pick Counter

application of force: 1.0N ~ 200.0N

the blade across the sample length:: 0 ~ 50.0mm

a set of weights: 20N*8; 10N*3; 5N*1; 2N*2; 1N*1; 0.1N*1

blade hardness: (56 ~ 63) HRC

Standard: ISO105-X12, D02, Bs1006 D02, DIN54021, IWS Tm165, JIS K6328, AATCC 8

Vertical pressure: 9N+/-10%

Weight: 6kg

Dimension: 660 x 160mm x 215mm (L x W x H)

Test station: 4

Measured pressure points: 0kPa, 1.75kPa, 3.5kPa, 7kPa, 14kPa, 20kPa

Pressure mode: 0.5~30) kPa, automatic adjustment

Timing range: 0-99999 seconds

Test station: 4

Measured pressure points: 0kPa, 1.75kPa, 3.5kPa, 7kPa, 14kPa, 20kPa

Pressure mode: 0.5~30) kPa, automatic adjustment

Timing range: 0-99999 seconds

Blade Model: 88-0121

Blade Speed: (2.5±0.5）mm/s

Dimension: 560×400×700mm（L×W×H

Weight: 40kg

load weight: 5±0.05N

sample size: 100mm*80mm

cutting stroke: 50mm

cutting line speed: 100mm/s(blade sine speed)

Test station: Can test two samples at the same time, each can do six buttons

Control method: Touch screen setting input direct action, the action is simple and convenient

Action mode: The cylinder drives the probe to reciprocate up and down

Test method: The buttons can be set to act at the same time, or the six buttons can be set to act in sequence, and several stations can be arbitrarily set to pause actions as needed
