Skyline Instruments Co.,LTD
We only manufacture Lab Testing Equipment
Sales & Support:
 |
| Place of Origin: | China |
| Brand Name: | SKYLINE |
| Certification: | CE |
| Model Number: | SL-F15 |
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | neogitable |
| Packaging Details: | plywood case |
| Delivery Time: | 10 working days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 1 unit / month |
| Application: | Applies To Check Thesingle Insulation Wire And Cable Vertical Spreading Test Which Total Section Area Less Than 0.5mm2 | Burning Time: | Continuously Setting Between 0.1-999.9S, During The Setting Time Flame Could Continuously Burning The Specimen |
|---|---|---|---|
| Temperature Measurement System: | According To GB/T5169.14-2007 And IEC60695-11-03 Standard Requirements, Including Temperature Copper (10g), K Type Thermocouple And Diameter Is 0.5 Mm With Stainless Steel Sheathed, Stopwatch And Thermometer Etc. | Standards: | IEC60332-1-1:2004, IEC60332-1-2:2004, IEC60332-1-3:2004, EN50265-1, EN50265-2-1 |
| Gas Flow Range: | 0.1-1L/min(100~1000cm3/min), Can Be Adjusted | Area Of Specimen: | Total Section Area Less Than 0.5mm2 |
| Gas: | Use High Purity Propane Gas Or Liquefied Petroleum Gas (provide By User-self) | Area Flow Range: | 220V±10%, 50Hz |
The Flammability Testing Equipment comes equipped with a combustion resistance device that is used to regulate the flame height and duration. The device allows users to set the burning time continuously between 0.1-999.9 seconds. During this time, the flame can continuously burn the specimen, allowing users to accurately measure the combustion resistance of the material. The equipment also features an ignition point monitor that detects the exact moment when the material catches fire. This feature allows users to accurately determine the ignition point of the material being tested.
The Flammability Testing Equipment is designed to be user-friendly and easy to operate. The equipment is equipped with a touch screen display that allows users to easily set and adjust the testing parameters. The equipment is also equipped with a safety interlock system that ensures the equipment is safe to operate at all times. The equipment is made from high-quality materials and is built to last, ensuring users get the most value for their investment.
The Flammability Testing Equipment is commonly used in a variety of industries, including textiles, plastics, and automotive. The equipment is used to test the flammability of materials used in these industries to ensure they meet various safety standards. The equipment is also used by research and development teams to test the flammability of new materials and products before they are introduced to the market.
In conclusion, the Flammability Testing Equipment is an essential product for anyone who needs to determine the combustion resistance of various materials and products. The equipment is equipped with a combustion resistance device and an ignition point monitor, making it an accurate and reliable testing tool. The equipment is also user-friendly and easy to operate, making it a popular choice for a variety of industries.
Inflammability Checker Tool, Inflammability Checker Tool, Inflammability Checker Tool
| Product Attribute | Value |
|---|---|
| Product Name | Fireproofness Assessment Apparatus |
| Also Known As | Combustibility Measurement Machine, cable testing machine |
| Gas | High purity propane gas or liquefied petroleum gas (provided by user-self) |
| Gas Flow Range | 0.1-1L/min (100~1000cm3/min), Can Be Adjusted |
| Power Supply | 220V±10%, 50Hz |
| Area Flow Range | 0.1-1m3/h (1.66~16.6dm3/min), Can Be Adjusted |
| Standards | IEC60332-1-1:2004, IEC60332-1-2:2004, IEC60332-1-3:2004, EN50265-1, EN50265-2-1 |
| Chamber Size | W300 * D450 * H1200mm |
| Specimen Length | 600±25mm |
| Testing Temperature | This device is located in a stuffiness room and the temperature is kept at 23±10℃ for testing |
| Area Of Specimen | Total Section Area Less Than 0.5mm2 |
| Burner | 46~78mm for height of blue luminous cone, 148~208mm for total height of flame, which according to GB/T5169.14-2007, IEC60695-11-2 |
The SKYLINE SL-F15 has an area flow range of 0.1-1m3/h (1.66~16.6dm3/min) which can be easily adjusted. This equipment meets the following standards: IEC60332-1-1:2004, IEC60332-1-2:2004, IEC60332-1-3:2004, EN50265-1, EN50265-2-1. The power supply required is 220V±10%, 50Hz. The burner used in this equipment has a height of 46~78mm for the height of blue luminous cone and 148~208mm for the total height of flame, which is in accordance with GB/T5169.14-2007 and IEC60695-11-2.
The SKYLINE SL-F15 is suitable for various applications such as testing the flame retardant properties of materials used in electrical equipment, cables, and other products. It can also be used in research and development to improve product safety and meet industry standards. This equipment is particularly useful for those in the manufacturing industry who want to ensure their products meet safety regulations to prevent fire hazards.
In conclusion, the SKYLINE SL-F15 is a reliable and efficient flammability testing equipment suitable for various applications. Its adjustable area flow range, compliance with international standards, and sturdy packaging make it an ideal choice for those who need to conduct fireproofness assessments or combustion resistance tests. Order now and get the peace of mind that comes with knowing your products are safe from fire hazards.
Our Flammability Testing Equipment product comes with comprehensive technical support and services to ensure that our customers get the most out of their equipment. Our team of experts is available to answer any questions you may have about the product, as well as provide training and assistance with installation and calibration.
In addition, we offer maintenance and repair services to keep your equipment working at its best. Our experienced technicians can perform routine maintenance and repairs on-site or at our facility, ensuring minimal downtime for your operations.
For customers who require specialized testing services, we offer a range of testing options using our Flammability Testing Equipment. Our testing services are conducted by trained professionals and are designed to meet industry standards and regulations.
Product Packaging:
Shipping:
What is the brand of this Flammability Testing Equipment?
The brand name of this Flammability Testing Equipment is SKYLINE.
2.What is the model number of this Flammability Testing Equipment?
The model number of this Flammability Testing Equipment is SL-F15.
3.Does this Flammability Testing Equipment have any certification?
Yes, this Flammability Testing Equipment has CE certification.
4.Where is this Flammability Testing Equipment manufactured?
This Flammability Testing Equipment is manufactured in China.
5.What are the payment terms for purchasing this Flammability Testing Equipment?
The payment terms for purchasing this Flammability Testing Equipment are T/T, Western Union, and MoneyGram.
