8 Stations Pneumatic Button Life Tester with Touch Screen Control for Key Durability Testing

Name: 8 Stations Pneumatic Button Life Tester with Touch Screen Control for Key Durability Testing
Brand: SKYLINE INSTRUMENTS CO.,LTD
SKU: SL-P40
Price: 4,500.00 USD
Availability: InStock

Brand Name:	SKYLINE
Model Number:	SL-P40
MOQ:	1 unit
Price:	negoitable
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	1 unit

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Calibration certificate

SKYLINE:

Button Life Test Machine

Test Station:

8 (work At The Same Time)

Load Weight:

50, 100, 200, 300, 500g Each Four (optional)

Test Speed:

5~60/min (knob Adjustable, LCD Display)

Working Power:

AC220v, 50HZ

Packaging Details:

Plywood case

Supply Ability:

1 unit

Highlight:

8 Stations Button Life Tester

Pneumatic Key Durability Tester

Touch Screen Control Button Life Tester

Product Description

Key Durability Tester for Switches, Keyboards, and Phones - 8 Station Pneumatic Button Life Fatigue Testing Machine

Product Introduction

The Touch Screen Pneumatic Button Life Tester is designed for fatigue testing of switches and buttons on mobile phones, remote controls, calculators, walkie-talkies, telephones, and other electronic consumer products. This pneumatic key life testing machine uses driving cylinders with adjustable press load, cycles, and speed to simulate actual product service life by testing buttons in sequential order (1-2-3-4-5-6).

Key Features

Specialized device for performing precise button fatigue tests
Compact, well-designed structure with small cylinders for impact testing
Adjustable pressing position and striking speed for various button types
Direct key life count detection using sensors
Touch screen control for cyclic or simultaneous testing
Stable operation with low noise and minimal maintenance requirements

Technical Specifications

Test Station	Can test two samples simultaneously, each testing six buttons
Control Method	Touch screen setting with direct action input for simple operation
Action Mode	Cylinder-driven probe reciprocating vertically
Test Method	Buttons can act simultaneously or in sequence, with customizable station pausing
Test Speed	10-60 cycles/minute (manually adjustable)
Mobile Phone Thickness	10-50mm capacity
Clamping Fixture	Secures both sides of lower cover
Height Adjustment	Manual direct adjustment
Dimensions	600×450×520mm (L×W×H)
Power Supply	220V
Weight	Approximately 55kg
