Office Chair & Indoor Chair Stability Tester Forward and Rear Stability Testing ANSI/BIFMA X5.1-2017 11;12 BIFMA X 5.4

Name: Office Chair & Indoor Chair Stability Tester Forward and Rear Stability Testing ANSI/BIFMA X5.1-2017 11;12 BIFMA X 5.4
Brand: SKYLINE INSTRUMENTS CO.,LTD
SKU: SL-T23
Price: 4,500.00 USD
Availability: InStock

Brand Name:	SKYLINE
Model Number:	SL-T23
MOQ:	1
Price:	negoitable
Payment Terms:	T/T
Supply Ability:	1 unit/Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Horizontal Pull Force:

20N

Engine Power:

About 20W

Instrument Dimensions:

1350mmx1000mmx1850mm (L * W * H)

Main Test Items:

Office Chair Forward And Backward Stability Test

Loading Weight:

Rear Stability Weight:130kg

Packaging Details:

Plywood case

Supply Ability:

1 unit/Month

Highlight:

Office Chair Stability Tester

Indoor Chair Stability Tester

Product Description

Product Information

The purpose of these tester is to evaluate the front and rear stability of chairs.

Testing Standards

ANSI/BIFMA X5.1-2017 11;12

Specification

Cylinder Stock	250mm
Horizontal Force	20N
The engine power	About 20W
Loading Position	60mm away from the front of center of the seat surface
Seat Compression plate	Diameter 200mm,arc surface300mm
Machine Dimension	1350 mmx1000mmx1850mm (L * W * H)
Test Area	780mm740mm(LW)
Main test items	Office chair forward and backward stability test
Loading Weight	Forward stability: European standard 60kg, American standard 61kg;
Loading Weight	Rear stability weight:130kg

Office Chair & Indoor Chair Stability Tester Forward and Rear Stability Testing ANSI/BIFMA X5.1-2017 11;12 BIFMA X 5.4 0

Office Chair & Indoor Chair Stability Tester Forward and Rear Stability Testing ANSI/BIFMA X5.1-2017 11;12 BIFMA X 5.4 1
