EN71-1 Direct Current Field Dc Gaussmeter Resolution 5 G High Accuracy

EN71-1 Direct current field Gauss meter with a resolution of 5 G

Large and easy-to-read display.

The alternate magnetic flux density, in addition to direct magnetic flux density, can be measured.(50/60 Hz)

A wide measuring range from (0.1Gs-3000Gs)/(1Gs-30KG) (Direct current)

The high resolution measuring mode ensures more accurate measurement. (Resolution 0.01 mT =0.1 G)

The unit of display can be changed over between “mT ”and “G ”.

High dustproof by use of sheet keys.

The auto power off function prevents useless waste of the battery.

an active area diameter of (0,75) mm, a distance between the active area and probe tip of (0,38 ± 0,13) mm.

complies with EN71-1 8.35

Direct current field Gauss meter with a resolution of 5 G, and capable of determining the field to

an accuracy of 1,5 % or better.

The meter shall have an axial type probe manufactured with

— an active area diameter of (0,76 ± 0,13) mm;

— a distance between the active area and probe tip of (0,38 ± 0,13) mm.
