ISO 4210 Bicycle / Bike Wheel Holding Force Disengagement Tester PLC

Name: ISO 4210 Bicycle / Bike Wheel Holding Force Disengagement Tester PLC
Brand: SKYLINE INSTRUMENTS CO.,LTD
SKU: SL-BT103
Price: 4,500.00 USD
Availability: InStock

Brand Name:	SKYLINE
Model Number:	SL-BT103
MOQ:	1 Unit
Price:	negotiated
Payment Terms:	L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability:	10 unit / month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

CE , Calibration Certificate

Load Element Capacity:

500kgf

Timer:

0 ~60 S Adjustable

Accuracy:

±0.1s

Loading Mode:

Electric Loading

Control System:

PLC Touch Human-machine Interface Control

Dimension:

2000 X 850 X 2000mm(W*D*H)

Weight:

160kg

Power Supply:

AC220V, 15A

Packaging Details:

plywood case

Supply Ability:

10 unit / month

Highlight:

Bicycle Wheel Holding Force Tester

Bike Wheel Holding Force Tester

AC220V 15A Force Tester

Product Description

ISO 4210 Bicycle/Bike Wheel Holding Force Disengagement Tester

Test principles

According to EN14764:2005 , ISO4210-2014

Application Of Bicycle/Bike Wheel Holding Force Disengagement Tester

Fasten the wheel to the frame and fork with nuts, test the front wheel clamping force by applying a force of 500N symmetrically on both sides of the front axle in the direction of front wheel disassembly, and hold for 30s to check the relative displacement between the front axle and the fork. To test the rear wheel clamping force, apply a force of 1000N symmetrically on both sides of the rear axle in the direction of the rear wheel disassembly and hold for 30s to check the relative displacement between the rear axle and the frame.

Technical parameters

Load element capacity	500kgf
Timer	0 ~60 s adjustable
Accuracy	±0.1s
Loading mode	electric loading
Control system	PLC touch human-machine interface control
Dimension	2000 x 850 x 2000mm(WDH)
Weight	160kg
Power supply	AC220V, 15A
