Home ProductsLab Testing Equipment

Automatic Pull Rod Luggage And Bags Zipper Plastic Reciprocating Tester Metal Earphone Cycle Test Machine

Automatic Pull Rod Luggage And Bags Zipper Plastic Reciprocating Tester Metal Earphone Cycle Test Machine

  • Automatic Pull Rod Luggage And Bags Zipper Plastic Reciprocating Tester Metal Earphone Cycle Test Machine
  • Automatic Pull Rod Luggage And Bags Zipper Plastic Reciprocating Tester Metal Earphone Cycle Test Machine
  • Automatic Pull Rod Luggage And Bags Zipper Plastic Reciprocating Tester Metal Earphone Cycle Test Machine
  • Automatic Pull Rod Luggage And Bags Zipper Plastic Reciprocating Tester Metal Earphone Cycle Test Machine
Automatic Pull Rod Luggage And Bags Zipper Plastic Reciprocating Tester Metal Earphone Cycle Test Machine
Product Details:
Place of Origin: China
Brand Name: SKYLINE
Certification: calibration certificate
Model Number: SL-TL08
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negoitable
Packaging Details: Plywood case
Delivery Time: 35 working days
Payment Terms: Western Union, T/T, MoneyGram
Supply Ability: 2 pcs/ month
Contact Now
Detailed Product Description
SKYLINE: Automatic Pull Rod Luggage And Bags Zipper Plastic Reciprocating Tester Metal Earphone Cycle Test Machine Stroke: 75mm
Counter: LCD, 0-999,999 Transverse Clamping Device Width: 25mm
Total Weight Of Clamping Device: 0.28-0.34kg Distance Between Two Device: 6.35mm
Opening Angle Of Sample: 60° Power Supply: 220 /110 V 50/60 Hz 4 A
High Light:

abrasion testing equipment

,

brake testing equipment

Automatic Pull Rod Luggage and Bags Zipper Plastic Reciprocating Tester Metal Earphone Cycle Test Machine



Application

Electronic Durable Zipper Fatigue Testing Equipment, to determine the resistance to reciprocation of zipper (slide fastener), the test specimen is subjected to a specified number of cyclic operations whilst under lateral and longitudinal tension.

Electronic Durable Zipper Fatigue Testing Equipment catches the head of zipper to do reciprocating movement in a constant speed for 30 times per minute, Integral counter to stop the drive when a pre-selected count has been reached.



Specefications

 Stroke  75mm
 Motor  1/4HP
 Counter  LCD, 0-999,999
 Machine Size  280x550x660mm (LxWxH)
 Weight  40 KG
 Power  220 /110 V 50/60 Hz 4 A
 Transverse clamping device width  25mm
 Total weight of clamping device  0.28-0.34kg
 Distance between two device  6.35mm
 Opening Angle of sample  60°
 Interdigitation angle of sample  30°

Zipper Reciprocation Tester.pdf

Automatic Pull Rod Luggage And Bags Zipper Plastic Reciprocating Tester Metal Earphone Cycle Test Machine 0
