| Place of Origin: | China |
| Brand Name: | SKYLINE |
| Certification: | CE |
| Model Number: | DBF-3 |
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | negotiated |
| Packaging Details: | plywood case |
| Delivery Time: | 10 work days |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 1 unit/ month |
| Environmental Temperature: | -5℃-30℃ | Air Volume Of Blower: | (1-5) M³/min |
|---|---|---|---|
| Voltage And Power: | 220V±10%. 50Hz,300W | Gas Source: | Liquefied Petroleum Gas |
| Relative Humidity: | ≤85% | Timer Error: | ≤ 1s/h |
| High Light: | lab testing equipment,vertical flammability chamber |
||
Technical indicators
1.PLC+NA view professional software, touch screen control, easy operation
2. Backfire five-way thermocouple temperature,alarm when it comes to 220℃
3. Specimen Size: 900mm*900mm*5mm +0.2mm Plywood of five layers of first level
4. Time of Automatic Controlling——Temperature Rise and Record
5.Alarm when temperature of time back fire comes 220℃
Parameters
| Voltage and Power | 220V±10%. 50Hz,300W |
| Working Environment | indoor , no forced ventilation |
| Air Volume of Blower | (1-5) m³/min |
| Armored Thermocouple | Outer diameter ≤3mm, Wire diameter 0.5mm , Accuracy ≥II level, Range 1300℃ |
| Timer Error | ≤ 1s/h |
| Environmental Temperature | -5℃-30℃ |
| Relative Humidity | ≤85% |
| Gas Source | Liquefied petroleum gas |
| Test plate bracket | 760mm*760mm*1500mm |
| Control box | 800mm*500mm*500mm |
Design standards
GB12441-2005 <Grading and Testing Method of Function of Fireproof Of Facing Fire-retardant Coating——Method of large plate>
What is fireproof coating?
Exposure to the heat of a fire triggers a reaction, causing the intumescent paint to expand to up to 50 times its thickness and form a solid foam-like char. This char insulates the steel from the heat, so keeping it below the temperatures that would compromise it. Intumescent paint is the main coating used for steel.
