Name: Fabric / Leather Testing Equipment DIN 53325 For Leather Surface Crack
Brand: SKYLINE INSTRUMENTS CO.,LTD
SKU: SL-L05
Price: 4,500.00 USD
Availability: InStock

Home Products Leather Testing Equipment

Fabric / Leather Testing Equipment DIN 53325 For Leather Surface Crack

Product Details:

Place of Origin:	CN
Brand Name:	SKYLINE
Certification:	CE
Model Number:	SL-L05

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	negoitable
Packaging Details:	plywood case
Delivery Time:	15 work days
Payment Terms:	Western Union, MoneyGram, T/T

Contact Now

Detailed Product Description

SKYLINE:	Leather Crack Tester	Standard:	DIN 53325
Ball Diameter:	φ21mm, φ6.25mm	Scale Range:	0.05 ~ 25mm
Weight:	1.3kg	Volume:	φ7cm, H15cm
Highlight:	leather testing machine , rubber testing equipment

DIN 53325 Leather Testing Equipment Leather Surface Crack Tester

This device is used to test the upper, all kinds of thin leather and leather surface of the anti-cracking index.

Principle

The folder frame fixed the outer circumference of the specimen, and then hand to the way the speed of 12mm per minute, so that the ball from the inside of the leather from the top, when the leather surface cracks, the rise of the height value, that is cracked.

Main technical parameters

After the specimen is fixed diameter	φ25mm
Ball diameter	φ21mm, φ6.25mm
Scale range	0.05 ~ 25mm
Volume	φ7cm, H15cm
Weight (about)	1.3kg

Accessories

Transparent piece one pcs

Standard

DIN 53325
