UV Aging Test Chamber 450 X 450 X 450mm , Programmable Ozone Test Chamber

UV Aging Test Chamber 450 X 450 X 450mm , Programmable Ozone Test Chamber

  • UV Aging Test Chamber 450 X 450 X 450mm , Programmable Ozone Test Chamber
  • UV Aging Test Chamber 450 X 450 X 450mm , Programmable Ozone Test Chamber
  • UV Aging Test Chamber 450 X 450 X 450mm , Programmable Ozone Test Chamber
UV Aging Test Chamber 450 X 450 X 450mm , Programmable Ozone Test Chamber
Product Details:
Place of Origin: China
Brand Name: SKYLINE
Certification: CE
Model Number: SL-E03
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negoitable
Packaging Details: plywood case
Delivery Time: 15 working days
Payment Terms: Western Union, T/T, MoneyGram
Supply Ability: 10 pcs/ month
Contact Now
Detailed Product Description
SKYLINE: Ozone Aging Test Chamber Dimension Of Test Chamber: 450X450X450mm
Material: Interior Material: SUS# Stainless Steel Plate Test Chamber Temperature: RT~+60℃
Refrigeration: Cascade Refrigeration System Warranty: 18 Months
High Light:

environmental testing equipment

,

environmental testing machine

Enviromental Test Chamer Programmable Ozone Aging Resistance Test Chamber



Use of environmental test chamber

Ozone Test chamber is used for testing rubber and polymer.

Ozone aging test chamber is a major factor in rubber cracking although it is rare in the atmosphere, ozone aging tank simulates and enhance the condition of ozone in the atmosphere to study the effects of ozone on rubber, and then identify and evaluate the method to resist ozone and aging for rubber, adopt effective anti-aging measures to enhance the life of rubber products

Put the sample in certain density ozone environment, after having certain discoloration or the scheduled time and compare with the standard card.


Applications of Ozone Test Chamber

• Accelerated Aging Studies
• Product Quality Control
• Research & Development
• Quality Assurance


Standards

OZ air series "ozone test chambers" are manufactured with flexibility for testing with following standards
• ASTM D 518 IS-3400 (Part-20)
• ASTM D 1149 ISO 1431-1 : 1989
• ASTM D 1171
• ASTM D 3395
• ASTM D 4575
• BIS, ISO, DIN, MIL
Stainless chamber walls are sealed with high-grade fiber gasket to assure leak proof operation
Ozone concentration 0~1000pphm
Test chamber temperature RT~+70℃
surface temperature fluctuations degrees + /-0.5 ℃
Load 10 kg



Technical parameters

 Model  Ozone Test Chamber Manufacturer
 Ozone concentration  0~1000pphm adjustable
 Relative humidity  60%RH above
 Temperature  RT+10~+70℃
 Ozone produced mode  Ozone generator or UV absorption method
 Inside air velocity  over 2 feet/sec

 Degree of ozone concentration

fluctuation

 10%
 Inside size  500×500×600mm
 Air flow  A.0-6 cfm;B. 10-20 cfh
 Weight  250kg
 Power  AC220V,15A
 Accessories  tensile fixture 6 groups



Equipment by the occurrence of silent and efficient ozone generator ozone gas, and a certain amount of air processed, the switch in the mixture into the chamber, the continuous line UV detector to detect the concentration of ozone, ozone generator control feedback to the systems to control system settings according to the occurrence of effective control of ozone to the ozone chamber to maintain the appropriate concentration of work by heating humidification systems to meet all the test conditions.



Applicable industries

It is widely used to control products quality in measuring quality control; Rubber & Plastics; automobile production; wire and cable; packing materials; instruments and meters; medical equipment; civilian nuclear energy; civil aviation; colleges and universities; research laboratories; inspection arbitration, and technical supervision departments and other rubber products.



UV Aging Test Chamber 450 X 450 X 450mm , Programmable Ozone Test Chamber 0
