Professional Environmental Test Chamber 110L PVC Salt Spray Test Equipment

Professional Environmental Test Chamber 110L PVC Salt Spray Test Equipment

  • Professional Environmental Test Chamber 110L PVC Salt Spray Test Equipment
  • Professional Environmental Test Chamber 110L PVC Salt Spray Test Equipment
  • Professional Environmental Test Chamber 110L PVC Salt Spray Test Equipment
  • Professional Environmental Test Chamber 110L PVC Salt Spray Test Equipment
  • Professional Environmental Test Chamber 110L PVC Salt Spray Test Equipment
Professional Environmental Test Chamber 110L PVC Salt Spray Test Equipment
Product Details:
Place of Origin: China
Brand Name: SKYLINE
Certification: CE, calibration certificate
Model Number: SL-E02
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Negoitable
Packaging Details: plywood case
Delivery Time: 15 working days
Payment Terms: Western Union, T/T, MoneyGram
Supply Ability: 10 pcs/ month
Contact Now
Detailed Product Description
SKYLINE: Salt Spray Test Chamber Volume: 110L
Material: PVC Sheet, Thickness 5 Mm Standard: CNS3627, 3885, 4159, 7669, 8886, JIS Do201, H8502, H8610, K5400, Z2371, ISO3768, 3769, 3770, 9227, ASTM B117, B268
Saturated Air Drums: 47℃±1℃ Material For Saturated Air Barrel: SUS #304 Stainless Steel Barrel High Pressure Barrel
High Light:

environmental testing equipment

,

uv accelerated weathering tester

110L PVC Salt Spray Test Chamber Environmental Test Chamber


Application


The Salt Spray Chamber are specialized to test the performance of the products for its surface of various materials after treatment of corrosive protection by means of painting, coating, galvanizing, anodizing and of lubricant.


Material


1) Laboratory using PVC sheet, thickness 5 mm, the temperature reaches 80 degree Celsius;
2) Laboratory closure with high impact acrylic sheet, 6 mm thick;
3) Supplementary bottles of reagents attached to the water level perspective with hidden windows, clean easy, not easy to break;
4) Saturated air barrel using SUS #304 stainless steel barrel high pressure barrel insulation is best;
5) Laboratory basketball adopt flat indexing frame, adjustable angle, surrounded by mist side down exactly the same place the large number of test pieces
Salt spray test NSS,ACSS
laboratory 35℃±1℃
Saturated air drums 47℃±1℃
Corrosion test NSS.ACSS
laboratory 50℃±1℃
Saturated air drums 63℃±1℃
Comply to international standards: CNS3627, 3885, 4159, 7669, 8886, JIS Do201, H8502, H8610, K5400, Z2371, ISO3768, 3769, 3770, 9227, ASTM B117, B268


Technical parameters

 Inside box size(cm)

 60x45x40

 90x60x50

 120x80x50

 Outside box size(cm)

 113*107*63

 146*128*91

 224*150*160

 Testing room temperature

 Salt test (NSS ACSS)35±1 degree / Corrosion Test (CASS)50±1 degree

 Pressure barrel temperature

 Salt test (NSS ACSS)47±1 degree / Corrosion Test (CASS)63±1 degree

 Brine temperature

 35±1 degree or 50±1 degree

 Testing room Capacity

 108L

 270L

 800L

 Brine tank capacity

 15L

 25L

 40L

 Salt concentration

 The concentration of sodium chloride 5% or the 5% concentration of sodium chloride add 0.26g per liter of copper chloride (CuCl2 2H2O)

 Air pressure

 1.00±0.01kgf/cm2

 Spray volume

 1.0~2.0ml/80cm2/h (working at least 16 hours, and then take the average)

 Testing room relative humidity

 85% above

 PH

 6.5~7.2 3.0~3.2

 Spray form

 Programmable spray (Including continuous and intermittent spray)

 Power

 AC220V1Φ10A

AC220V1Φ15A

AC220V1Φ20A



What is salt spray test machine?

Salt spray testing is a laboratory simulation of a corrosive saline environment. It is used as an accelerated means of testing the ability of surface coatings to withstand atmospheric corrosion. ... Then the front of the panel is “scribed” with a sharp tool to produce a scratch through the coating to the metal substrate.

110L Salt Spray Test Chamber.pdf
