1000V Fire Testing Equipment Wire & Cable Resistance To Fire With Water IEC60331-11

Product Details:

Place of Origin:	China
Brand Name:	SKYLINE
Certification:	CE
Model Number:	SL-7606S

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	negotiated
Packaging Details:	plywood case
Delivery Time:	10 work days
Payment Terms:	T/T, L/C, Western Union, MoneyGram
Supply Ability:	1 unit/ month

Contact Now

Detailed Product Description

Standards:

IEC60331-11, IEC60331-21, IEC 60331-1etc.

Testing Power:

AC0-1000V

Testing Temperature:

650±40℃

Specimen Size:

Length About 400mm

High Light:

flammability test chamber

flammability testing labs

1000V Flammability Testing Equipment Wire & Cable Resistance to Fire with Water IEC60331-11

Standards

According to IEC60331-11, IEC60331-21, IEC 60331-1, IEC 60331-2, EN50200, EN50362, BS6387: 1994, BS7846, BS8431-1, BS8434-2, BS8491 etc.

Use

Used for testing wires & cables with the rated voltage through the different refractory level,detect the fire resistance of the insulation, check insulation whether breakdown and circuit’s integrality.

Main parameters

Testing power	AC0-1000V, continuously adjustable, current: AC0.01-0.70A,four circuits independent continuously adjustable
Ribbon burner	nozzle length is 500mm, width is 15mm, contain the venturi mixer
Burning gas	propane or other gas
Testing temperature	650±40℃
Specimen size	length about 400mm
Temperature sensor	ø 2.0 mm Platiniridium temperature sensor, below the specimen
Spraying head pressure	During 250-350Kpa, flowing speed: 0.25-0.3L/S.m2

What is a test fire and why is it important?
What Is Fire Testing? Fire testing intends to understand the influence of a direct flame on a material or product. Companies may analyze the effect on wiring or cable, building materials or furnishings.
