Steel Material Lab Testing Equipment Stroller Brake Testing Equipment With Adjustable Stabilizers

Steel Material Lab Testing Equipment Stroller Brake Testing Equipment With Adjustable Stabilizers

    • Steel Material 	Lab Testing Equipment Stroller Brake Testing Equipment With Adjustable Stabilizers
    • Steel Material 	Lab Testing Equipment Stroller Brake Testing Equipment With Adjustable Stabilizers
    • Steel Material 	Lab Testing Equipment Stroller Brake Testing Equipment With Adjustable Stabilizers
    • Steel Material 	Lab Testing Equipment Stroller Brake Testing Equipment With Adjustable Stabilizers
    • Steel Material 	Lab Testing Equipment Stroller Brake Testing Equipment With Adjustable Stabilizers
  • Steel Material 	Lab Testing Equipment Stroller Brake Testing Equipment With Adjustable Stabilizers

    Product Details:

    Place of Origin: CHINA
    Brand Name: SKYLINE
    Certification: Calibration certificate
    Model Number: SL-S50

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negoitable
    Packaging Details: carton box
    Delivery Time: 3 work days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 1 unit
    Contact Now
    Detailed Product Description
    SKYLINE: Stroller Brake Tester Standards: EN71-1,ISO8124-1
    Material: Steel Slop Angel: 0~35°+/- 1°
    Weight: 70kg Warranty: 18 Months

    Lab Testing Equipment Stroller Brake Performance Tester


    Product description

    Covered with a surface of abrasive papers ( aluminium oxide P60 ) with its longitudinal axis parallel to the incline. Apply a

    force of (50+/-2) N in the direction in which the brake handle is normally operated. Apply the force to the brake handle at

    the point where it is normally applied in use. Determine whether the toy moves more than 5 cm.



    Testing Standards

    EN71-1,ISO8124-1



    Procedure

    Load the toy scooter using load B,with a nominal mass of 29,5 kg. Apply an additional load with a mass of (25 ± 0,5) kg on the foot brake 29,5 kg.
     Apply an additional load with a mass of (25 ± 0,5) kg on the foot brake.
    The platform shall be fitted with adjustable stabilizers in such a way that they allow the toy scooter
    to maintain a vertical position during the test, but such that they are unloaded when the toy scooter is in a
    vertical position. Attach the articulated arms to the handle bar and place the toy scooter on a plane inclined at (10 ± 1)° covered with a surface of abrasive paper (aluminium oxide P60) and with its longitudinal axis parallel to the incline (10 ± 1)° covered with a surface of abrasive paper (aluminium oxide P60)
    Ensure that the force required to hold the toy scooter stationary on the inclined plane, parallel to the plane, i less than 50 N.



    Technical parameters

     Performance degree  0-35degree
     Testing surface  Aluminium oxide P60
     Standards  EN71-1, ISO 8124-1, ASTM F963
     Accessories  Weights 50kg

    Steel Material 	Lab Testing Equipment Stroller Brake Testing Equipment With Adjustable Stabilizers
