ASTM E662 Smoke Density Chamber Smoke Densit Box Building Materials Flammability Tester For Vehicles Internal Material

ASTM E662 Smoke Density Chamber Smoke Densit Box Building Materials Flammability Tester For Vehicles Internal Material

    • ASTM E662 Smoke Density Chamber Smoke Densit Box Building Materials Flammability Tester For Vehicles Internal Material
    • ASTM E662 Smoke Density Chamber Smoke Densit Box Building Materials Flammability Tester For Vehicles Internal Material
    • ASTM E662 Smoke Density Chamber Smoke Densit Box Building Materials Flammability Tester For Vehicles Internal Material
  • ASTM E662 Smoke Density Chamber Smoke Densit Box Building Materials Flammability Tester For Vehicles Internal Material

    Product Details:

    Place of Origin: China
    Brand Name: SKYLINE
    Certification: CE
    Model Number: SL-E662

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiated
    Packaging Details: plywood case,
    Delivery Time: 10 work days
    Payment Terms: T/T, L/C, Western Union
    Supply Ability: 1 unit/ month
    Contact Now
    Detailed Product Description
    SKYLINE: ASTM E662 Smoke Density Tester Standards: ASTM E 662, BSI 6401, ISO 5659-2, NES 711
    Application: Vehicles Internal Material Certain Heat: 25KW/m2
    Weight: 350kg Dimensions: 1,600(W) ×820(D) × 2,150(H)mm
    Power Supply: 220V±10% 50HZ

    ASTM E662 Smoke Density Chamber, Smoke Densit Box For Vehicles Internal Material

    Product information

    When the thickness of the test sample was placed in a certain heat 25KW/m2, or cabinets open flames, smoke density chamber can measure their smoke density. The instrument applies to ASTM E 662, BS6401, ISO 5659, NES 711, NEPA 258 etc. Use the cone radiation furnace which in the ISO 5659, the user can arbitrarily adjust the heating condition by 10kw/m2 to 50kw/m2.The test is increasingly being used in vehicle interior materials and other low-power, non -flammable cables tests.



    Standard

    ASTM E 662: Standard test method for specific optical density of smoke generated by solid materials (The radiation cone is optional)

    BSI 6401: British Test Standard for specific smoke density indexISO 5659-2: Plastics-Smoke generation-Part2: Determination of optical density by a single-chamber test

    NES 711: Determination Of The Smoke Index Of The Products Of Combustion From Small Specimens Of Materials



    Features

    • Integrated design, 19 "analysis and control panel number

    •19 "industrial computer full control and the test can be done automatically

    • To carry the sample through moving the cylinder or automatically opening the top and bottom exhaust port (Highly resistant to pollution)

    • The coating of test box is easy to clean and resistant to chemical corrosion

    • Lock design is easy for one-time to close the door

    • Accurate display of smoke transmittance and smoke density

    • Preheating system of the chamber can accelerate the test and the accuracy is higher

    • When the furnace pressure increased rapidly during the test,the security blasting and tablet system can ensure the safety of users

    • Using MFC (mass flow controller) and DPT (pressure sensor) can improve the accuracy of pressure gauge and automatically let out the test

    • Using heat time (ISO 5659) without water pipes, portable water cooling system can complete the test on their own

    • In the ISO 5659 test, the load sensor can accurately measure the mass loss rate (Optional)

    • Equipped with a DAQ data acquisition program



    Specifications

     Size  1,600(W) ×820(D) × 2,150(H)mm
     Power  AC 220V, 50/60Hz, 15A
     Weight  350kg
     Instructions  Supply
     Exhaust  50ℓ/s
     Tools  Propane gas, pressure reducing valve











    ASTM E662 Smoke Density Chamber Smoke Densit Box Building Materials Flammability Tester For Vehicles Internal Material

    ASTM E662 Smoke Density Chamber Smoke Densit Box Building Materials Flammability Tester For Vehicles Internal Material
